Atomos Sumo 19SE HDR Monitor-Recorder and Switcher

Atomos Sumo 19SE HDR Monitor-Recorder and Switcher

The Atomos Sumo 19SE is a 19-inch 1200-nit HDR production monitor-recorder-switcher that combines a full-size DCI-P3 display with SDI/HDMI recording, multicamera switching and extensive rigging points for studio, DIT and on-set monitoring.

Its 1920 × 1080 SuperAtom IPS panel uses 10-bit 8+2 FRC processing and a quantum-dot, optically bonded display stack. The large screen makes waveform, focus and exposure tools practical for group viewing, while four HD-SDI inputs can be used for live switching and ISO/program recording workflows.

Sumo 19SE is built for mains or professional battery operation. A 4-pin XLR input accepts the included power supply and can also be used with compatible high-capacity V-Lock or Gold Mount battery solutions through optional plates.

Key Features

• 19-inch 1920 × 1080 HDR touchscreen
• 1200-nit brightness
• DCI-P3 colour gamut
• 10-bit 8+2 FRC panel processing
• Four HD-SDI input switching
• ISO plus program recording workflows
• Professional waveform, focus and exposure tools
• VESA 100 × 100 mounting

Display Specifications

• Panel: SuperAtom IPS capacitive touchscreen
• Size: 19 inches
• Resolution: 1920 × 1080
• Brightness: 1200 nits ±10%
• Bit Depth: 10-bit (8+2 FRC)
• Backlight: Edge-lit, optically bonded quantum dot
• Colour Gamut: DCI-P3
• Aspect Ratio: 16:9

Physical & Mounting Specifications

• Dimensions: 504 × 310 × 63mm
• Weight: 6.2kg
• VESA: 100 × 100mm
• Top Mounting: 4 × 1/4-inch-20, 2 × 3/8-inch
• Bottom Mounting: 6 × 1/4-inch-20, 3 × 3/8-inch
• Right Mounting: 4 × 1/4-inch-20, 2 × 3/8-inch
• Left Mounting: 2 × 1/4-inch-20, 1 × 3/8-inch
• Tally: Front and rear LEDs

Power Specifications

• Input Voltage: 12–16.8V DC
• Operating Power: 75W
• DC Input: 4-pin XLR
• Battery Support: 95Wh+ V-Lock or Anton/Bauer Gold Mount with optional mounting plates

What's Included

• Sumo 19SE
• Master Caddy II
• BattWing mounting bracket
• 2 × desktop feet with mounting screws
• XLR power supply

Compatibility

Recording format and frame-rate capability depend on the connected HDMI/SDI source and selected codec. Battery operation requires an appropriate professional battery plate/cable configuration. Confirm your input format and power system before installation.

Perfect For

• Video village and on-set monitoring
• Multicamera live switching
• DIT and colour-evaluation stations
• Studio and broadcast monitoring

Shipping Information

Please allow up to 4 to 12 BUSINESS days for delivery. For accurate shipping times, please check our shipping policy here.

Refunds & Returns

Returns are accepted within 30 days in line with our returns policy. Please check our returns policy before purchasing for full eligibility requirements.

Need help configuring Sumo 19SE?

Contact CameraHUB if you need help confirming SDI/HDMI formats, recording media or professional battery options.
