Atomos Sumo PRO-19 4K HDR DCI-P3 Monitor-Recorder and Switcher

Atomos Sumo PRO-19 4K HDR DCI-P3 Monitor-Recorder and Switcher

A 19-inch 4K UHD production monitor-recorder-switcher with 1200-nit HDR display, four-source SDI switching, high-resolution RAW recording and professional XLR audio.

Sumo PRO-19 is built for crews that need a large on-set display and a recorder/switcher in the same production station. Its 3840 × 2160 screen covers 100% Rec.709 and approximately 99% DCI-P3, while the SDI inputs can support four-camera ISO plus switched-program recording in compatible HD workflows. For higher-end acquisition, supported cameras can feed RAW up to 8Kp30, 6Kp30, 4Kp60 or 2Kp240.

Key Features

• 19-inch 3840 × 2160 4K UHD touchscreen
• 1200-nit brightness and 10-bit (8+2 FRC) display processing
• 100% Rec.709 and approximately 99% DCI-P3 coverage
• 2 × 12G-SDI plus 2 × 3G-SDI inputs
• HDMI 2.0 input/output up to 4K60p
• Four HD-SDI ISO recordings plus switched program in supported multicamera workflows
• RAW recording up to 8Kp30 on supported cameras
• Apple ProRes RAW, ProRes, Avid DNx and H.265 recording
• CFexpress Type B and USB 3.0 media support
• Wi-Fi 6E, Ethernet and AirGlu support

Display & Monitoring

• Resolution: 3840 × 2160
• Brightness: 1200 nits
• Bit Depth: 10-bit (8+2 FRC)
• Colour Coverage: 100% Rec.709, 99% DCI-P3, 99% NTSC, 87% BT.2020
• LUT Support: .Cube 17- and 33-point LUTs
• HDR Monitoring: Native, HLG, PQ and 3D LUT modes with log/HDR conversion

Recording & Connectivity

• RAW: up to 8Kp30 / 6Kp30 / 4Kp60 / 2Kp240 on supported cameras
• 4K DCI/UHD: up to 60p
• 1080p: up to 120p
• HDMI: HDMI 2.0 input/output up to 4K60p
• SDI: 2 × 12G-SDI + 2 × 3G-SDI inputs; 12G-SDI loop output
• Network: Wi-Fi 6E and RJ45 Ethernet
• USB: 2 × USB-C 2.0/3.0
• Signal Conversion: HDMI-to-SDI and SDI-to-HDMI

Audio & Timecode

• Audio: 24-bit / 48kHz PCM
• XLR: 2 × female analogue inputs and 2 × male analogue outputs
• Embedded Audio: 8-channel HDMI / 12-channel SDI
• Headphone: 3.5mm 2-channel output
• Timecode: HDMI/SDI embedded plus AirGlu wireless support
• LTC: dedicated BNC input in record mode

Physical & Power Specifications

• Dimensions: 474 × 315 × 62mm
• Weight: 7.1kg
• VESA: 100 × 100mm
• Construction: aluminium with ABS plastic
• Operating Power: 75W
• Input Voltage: 12–16.8V DC
• Battery Support: 95Wh+ V-Lock / Anton Bauer Gold Mount through optional plates and 4-pin XLR power arrangement

Perfect For

• Video village and client monitoring
• Multicamera switching and ISO recording
• DIT and studio production
• High-resolution RAW workflows

Compatibility Note

RAW resolution, codec availability, camera metadata and control depend on the connected camera and firmware. Confirm the intended camera, SDI/HDMI output and recording mode before purchasing.
