Portkeys PT5 III 5.4-inch HDMI Touchscreen Monitor

Portkeys PT5 III 5.4-inch HDMI Touchscreen Monitor

Check focus, exposure and framing on a larger view with the Portkeys PT5 III. This compact 5.4-inch touchscreen monitor accepts an HDMI camera signal and offers monitoring tools and imported 3D LUTs for on-set viewing.

A separate camera monitor can make exposure and focus tools easier to inspect than on a small camera display. The PT5 III combines a compact touchscreen with waveform, false colour and focus-assistance tools for a supported HDMI feed. Check the camera's output format and your chosen power supply when building the monitoring setup.

Key Features

• Waveform, false colour, histogram and focus peaking. These tools provide additional ways to assess the image rather than relying solely on how bright the picture appears.
• 3D LUT import through USB. A compatible look-up table provides a monitoring preview; it does not by itself change the recorded camera file.
• NP-F battery plate and USB-C power input. Confirm both the power source and connected equipment meet the voltage, current and protocol requirements.

Specifications

• Brand: Portkeys
• Display: 1920 × 1152 pixels, 8-bit
• Brightness: 800 nits
• Contrast: 1000:1
• HDMI input: up to DCI 4K30; output: up to 1080p60
• 3.5mm microphone input and headphone output
• Dimensions: 135.1 × 82.5 × 22mm
• Weight: 154.5g, as specified on the manufacturer product page
• Mounting: two 1/4-inch-20 points with locating-pin provision, on the bottom and right side
• Operating system: MOVNORM OS

Materials & Construction

• Touchscreen LCD design
• 1/4-inch mounting points on the bottom and side

What's Included

• 1 × Portkeys PT5 III monitor
• Protective case
• Sunshade and rubber covers
• USB key
• Full-size HDMI to full-size HDMI cable
• Full-size HDMI to Micro HDMI cable
• Portkeys MH-2 monitor mount

Why Choose Portkeys PT5 III 5.4-inch HDMI Touchscreen Monitor

• Combines a compact screen with exposure and focus aids for a lightweight camera rig.

Perfect For

• Mirrorless and DSLR filmmakers using a compatible HDMI output.
